Bambu X1C Home Assistant

https://book.cryd.de/books/projekte/page/bambu-x1c

Download JSON

YAML Code – Visuelle Karte

type: vertical-stack
cards:
  - type: picture-elements
    elements:
      - type: custom:config-template-card
        entities:
          - sensor.ams_0_bambu_x1c_tray_0
        element:
          type: state-icon
          entity: sensor.ams_0_bambu_x1c_tray_0
          icon: >-
            ${states['sensor.ams_0_bambu_x1c_tray_0'].state != 'Empty' ?
            'mdi:bullseye' : 'mdi:tray' }
        style:
          top: 28%
          left: 18%
          '--paper-item-icon-color': var(--tray_0_color)
          background-color: rgba(0,0,0,0.5)
          box-shadow: 0 0 5px 5px var(--tray_0_bg)
          border-radius: 50px
          '--mdc-icon-size': 2.4em
      - type: state-label
        entity: sensor.ams_0_bambu_x1c_tray_0
        attribute: type
        tap_action:
          action: none
        style:
          top: 77%
          left: 18%
          text-align: center
          font-size: 1em
          background-color: rgba(0,0,0,0.4)
          box-shadow: 0 0 5px 5px rgba(0, 0, 0, 0.4)
          border-radius: 50px
          pointer-events: none
      - type: custom:config-template-card
        entities:
          - sensor.ams_0_bambu_x1c_tray_1
        element:
          type: state-icon
          entity: sensor.ams_0_bambu_x1c_tray_1
          icon: >-
            ${states['sensor.ams_0_bambu_x1c_tray_1'].state != 'Empty' ?
            'mdi:bullseye' : 'mdi:tray' }
        style:
          top: 28%
          left: 39%
          '--paper-item-icon-color': var(--tray_1_color)
          background-color: rgba(0,0,0,0.5)
          box-shadow: 0 0 5px 5px  var(--tray_1_bg)
          border-radius: 50px
          '--mdc-icon-size': 2.4em
      - type: state-label
        entity: sensor.ams_0_bambu_x1c_tray_1
        attribute: type
        tap_action:
          action: none
        style:
          top: 77%
          left: 39%
          text-align: center
          font-size: 1em
          background-color: rgba(0,0,0,0.4)
          box-shadow: 0 0 5px 5px rgba(0, 0, 0, 0.4)
          border-radius: 50px
          pointer-events: none
      - type: custom:config-template-card
        entities:
          - sensor.ams_0_bambu_x1c_tray_2
        element:
          type: state-icon
          entity: sensor.ams_0_bambu_x1c_tray_2
          icon: >-
            ${states['sensor.ams_0_bambu_x1c_tray_2'].state != 'Empty' ?
            'mdi:bullseye' : 'mdi:tray' }
        style:
          top: 28%
          left: 61%
          '--paper-item-icon-color': var(--tray_2_color)
          background-color: rgba(0,0,0,0.5)
          box-shadow: 0 0 5px 5px  var(--tray_2_bg)
          border-radius: 50px
          '--mdc-icon-size': 2.4em
      - type: state-label
        entity: sensor.ams_0_bambu_x1c_tray_2
        attribute: type
        tap_action:
          action: none
        style:
          top: 77%
          left: 61%
          text-align: center
          font-size: 1em
          background-color: rgba(0,0,0,0.4)
          box-shadow: 0 0 5px 5px rgba(0, 0, 0, 0.4)
          border-radius: 50px
          pointer-events: none
      - type: custom:config-template-card
        entities:
          - sensor.ams_0_bambu_x1c_tray_3
        element:
          type: state-icon
          entity: sensor.ams_0_bambu_x1c_tray_3
          icon: >-
            ${states['sensor.ams_0_bambu_x1c_tray_3'].state != 'Empty' ?
            'mdi:bullseye' : 'mdi:tray' }
        style:
          top: 28%
          left: 83%
          '--paper-item-icon-color': var(--tray_3_color)
          background-color: rgba(0,0,0,0.5)
          box-shadow: 0 0 5px 5px var(--tray_3_bg)
          border-radius: 50px
          '--mdc-icon-size': 2.4em
      - type: state-label
        entity: sensor.ams_0_bambu_x1c_tray_3
        attribute: type
        tap_action:
          action: none
        style:
          top: 77%
          left: 83%
          text-align: center
          font-size: 1em
          background-color: rgba(0,0,0,0.4)
          box-shadow: 0 0 5px 5px rgba(0, 0, 0, 0.4)
          border-radius: 50px
          pointer-events: none
      - type: state-badge
        entity: sensor.ams_0_bambu_x1c_humidity
        style:
          top: 15%
          left: 29%
          color: transparent
      - type: state-badge
        entity: sensor.ams_0_bambu_x1c_temp
        style:
          top: 15%
          left: 72%
          color: transparent
    image: /local/ams.png
    style: |
      ha-card {
        background: none !important;
        border: none !important;
        --tray_0_color: {% if is_state('sensor.ams_0_bambu_x1c_tray_0', 'Empty') %} grey; {% else %} {{
            state_attr('sensor.ams_0_bambu_x1c_tray_0', 'color') }}; {% endif %}
        --tray_1_color: {% if is_state('sensor.ams_0_bambu_x1c_tray_1', 'Empty') %} grey; {% else %} {{
            state_attr('sensor.ams_0_bambu_x1c_tray_1', 'color') }}; {% endif %}
        --tray_2_color: {% if is_state('sensor.ams_0_bambu_x1c_tray_2', 'Empty') %} grey; {% else %} {{
            state_attr('sensor.ams_0_bambu_x1c_tray_2', 'color') }}; {% endif %}
        --tray_3_color: {% if is_state('sensor.ams_0_bambu_x1c_tray_3', 'Empty') %} grey; {% else %} {{
            state_attr('sensor.ams_0_bambu_x1c_tray_3', 'color') }}; {% endif %}
        --tray_0_bg: {% if is_state_attr('sensor.ams_0_bambu_x1c_tray_0', 'id', state_attr('sensor.current_ams_filament_in_use', 'id')) %} rgba(255, 255, 126, 0.5); {% else %} rgba(0,0,0,0.5); {% endif %}
        --tray_1_bg: {% if is_state_attr('sensor.ams_0_bambu_x1c_tray_1', 'id', state_attr('sensor.current_ams_filament_in_use', 'id')) %} rgba(255, 255, 126, 0.5); {% else %} rgba(0,0,0,0.5); {% endif %}
        --tray_2_bg: {% if is_state_attr('sensor.ams_0_bambu_x1c_tray_2', 'id', state_attr('sensor.current_ams_filament_in_use', 'id')) %} rgba(255, 255, 126, 0.5); {% else %} rgba(0,0,0,0.5); {% endif %}
        --tray_3_bg: {% if is_state_attr('sensor.ams_0_bambu_x1c_tray_3', 'id', state_attr('sensor.current_ams_filament_in_use', 'id')) %} rgba(255, 255, 126, 0.5); {% else %} rgba(0,0,0,0.5); {% endif %}
      }
  - type: picture-elements
    elements:
      - type: state-badge
        entity: sensor.x1c_bambu_x1c_bed_temperature
        style:
          top: 75%
          left: 50%
          color: transparent
      - type: state-badge
        entity: sensor.x1c_bambu_x1c_nozzle_temperature
        style:
          top: 32%
          left: 50%
          color: transparent
      - type: state-badge
        entity: sensor.x1c_bambu_x1c_chamber_temperature
        style:
          top: 32%
          left: 80%
          color: transparent
      - type: state-icon
        entity: light.x1c_bambu_x1c_chamber_light
        tap_action:
          action: toggle
        style:
          top: 32%
          left: 12%
          transform: scale(1.5,1.5)
    image: /local/x1c.png
    style: |
      ha-card {
        background: none !important;
        border: none !important;
        --tray_0_color: {% if is_state('sensor.ams_0_bambu_x1c_tray_0', 'Empty') %} grey; {% else %} {{
            state_attr('sensor.ams_0_bambu_x1c_tray_0', 'color') }}; {% endif %}
        --tray_1_color: {% if is_state('sensor.ams_0_bambu_x1c_tray_1', 'Empty') %} grey; {% else %} {{
            state_attr('sensor.ams_0_bambu_x1c_tray_1', 'color') }}; {% endif %}
        --tray_2_color: {% if is_state('sensor.ams_0_bambu_x1c_tray_2', 'Empty') %} grey; {% else %} {{
            state_attr('sensor.ams_0_bambu_x1c_tray_2', 'color') }}; {% endif %}
        --tray_3_color: {% if is_state('sensor.ams_0_bambu_x1c_tray_3', 'Empty') %} grey; {% else %} {{
            state_attr('sensor.ams_0_bambu_x1c_tray_3', 'color') }}; {% endif %}
        --tray_0_bg: {% if is_state_attr('sensor.ams_0_bambu_x1c_tray_0', 'id', state_attr('sensor.current_ams_filament_in_use', 'id')) %} rgba(255, 255, 126, 0.5); {% else %} rgba(0,0,0,0.5); {% endif %}
        --tray_1_bg: {% if is_state_attr('sensor.ams_0_bambu_x1c_tray_1', 'id', state_attr('sensor.current_ams_filament_in_use', 'id')) %} rgba(255, 255, 126, 0.5); {% else %} rgba(0,0,0,0.5); {% endif %}
        --tray_2_bg: {% if is_state_attr('sensor.ams_0_bambu_x1c_tray_2', 'id', state_attr('sensor.current_ams_filament_in_use', 'id')) %} rgba(255, 255, 126, 0.5); {% else %} rgba(0,0,0,0.5); {% endif %}
        --tray_3_bg: {% if is_state_attr('sensor.ams_0_bambu_x1c_tray_3', 'id', state_attr('sensor.current_ams_filament_in_use', 'id')) %} rgba(255, 255, 126, 0.5); {% else %} rgba(0,0,0,0.5); {% endif %}
      }

YAML Code – Print Details

type: vertical-stack
cards:
  - type: custom:mushroom-title-card
    title: ''
    subtitle: Print Details
    alignment: center
  - type: custom:mushroom-entity-card
    entity: sensor.x1c_bambu_x1c_stage
    name: Task
    icon: mdi:file-tree
  - type: horizontal-stack
    cards:
      - type: custom:mushroom-entity-card
        entity: sensor.x1c_bambu_x1c_print_progress
        name: Fortschritt
        icon: mdi:progress-clock
      - type: custom:mushroom-entity-card
        entity: sensor.x1c_bambu_x1c_subtask
        name: Druckobjekt
        icon: mdi:ufo
  - type: vertical-stack
    cards: []
  - type: custom:mushroom-entity-card
    entity: sensor.x1c_bambu_x1c_print_remaining_time
    name: Verbleibend
    icon: mdi:clock-time-eight

YAML Code – Fans

type: entities
entities:
  - entity: sensor.x1c_bambu_x1c_cooling_fan
    name: Bauteillüfter
  - entity: sensor.x1c_bambu_x1c_big_fan1
    name: Bauteil Zusatzlüfter
  - entity: sensor.x1c_bambu_x1c_big_fan2
    name: Gehäuse Lüfter
  - entity: sensor.x1c_bambu_x1c_heatbreak_fan
    name: Hotend Lüfter

Automation: Drucker ausschalten nach Druck incl. Abkühlungsphase

alias: 3D Drucker automatische Abschaltung
description: ""
trigger:
  - platform: numeric_state
    entity_id: sensor.x1c_bambu_x1c_heatbreak_fan
    below: 1
condition: []
action:
  - service: switch.turn_off
    data: {}
    target:
      entity_id: switch.STECKDOSE-DRUCKER   # hier bitte den Switch der smarten Steckdose angeben
  - service: automation.turn_off
    data: {}
    target:
      entity_id: automation.3d_drucker_automatische_abschaltung
mode: single

YAML Code – Automatisierungsbutton

type: custom:mushroom-template-card
primary: Abschaltung nach Druck
secondary: '{{ states(''sensor.x1c_bambu_x1c_print_remaining_time'') }} Minuten verbleibend'
icon: mdi:timer
icon_color: |-
  {% if is_state('automation.3d_drucker_automatische_abschaltung', 'on') %}
    yellow
  {% endif %}
tap_action:
  action: call-service
  service: automation.toggle
  data: {}
  target:
    entity_id: automation.3d_drucker_automatische_abschaltung

YAML Code – Script

alias: 3D Drucker ausschalten
sequence:
  - if:
      - condition: numeric_state
        entity_id: sensor.x1c_bambu_x1c_heatbreak_fan
        above: 1
    then:
      - service: notify.alexa_media
        data:
          target:
            - media_player.buro
            - media_player.kuche
            - media_player.wohnzimmer
            - media_player.badezimmer
            - media_player.schlafzimmer
          data:
            type: announce
          message: Ausschalten nicht möglich wegen aktivem Druck
    else:
      - service: switch.toggle
        data: {}
        target:
          entity_id: switch.3d_drucker_on_off                       #hier musst du deine Steckdose angeben
      - service: button.press
        data: {}
        target:
          entity_id: button.x1c_bambu_x1c_reset_filter
mode: single

YAML Code für Button

type: custom:mushroom-entity-card
entity: switch.3d_drucker_on_off
icon: mdi:power
icon_color: yellow
layout: horizontal
name: X1 Carbon
secondary_info: none
tap_action:
  action: call-service
  service: script.3d_drucker_ausschalten
  data: {}
  target: {}
